    Double Components Electronics Potting Sealant Heat Resistant Processing Compound

    Ask Lasest Price
    Brand Name : Lianti
    Model Number : KDW-3582(1:1)
    Certification : ISO9001
    • Product Details
    • Company Profile

    Double Components Electronics Potting Sealant Heat Resistant Processing Compound

    Two-component High Ambient Heat Conduction Electronics Potting Heat Resistant Processing Compound

    Product Display
    Double Components Electronics Potting Sealant Heat Resistant Processing Compound
    Product Description

    Performance.

    KDW-3582(1:1) is used on all kinds of componets of potting sealing and protection. It can be deeply cured, and with good liquidity, UV resistance, weather resistance, rain resistance and dirt resistance after mixed. And it can serve for a long time on outdoor products of fixation, waterproof, dustproof and anticreep.

    Application.

    1. Automotive electronics module

    2. Power control module

    3. Solar panels junction box LED screen

    4. LED wall washer, LED module, etc.

    Characters.

    1. Two components silicone potting compound, condensation type;
    2. Low viscosity, easy to process, strong maneuverability;
    3. Low shrinkage rate, no corrosion, no stress;
    4. Excellent high temperature electrical insulation, thermal conductivity and stability;

    5. Good waterproof and dampproof performance.

    Detailed Images
    Double Components Electronics Potting Sealant Heat Resistant Processing Compound
    Property
    Unused
    Used
    A
    B
    Uncured
    Color
    White/Gray
    White
    White/Gray
    Viscosity (mpa·s)
    4800
    4600
    4700
    Density (g/cm³)
    1.50~1.60
    1.50~1.60
    1.50~1.60
    Allowable operating time (25℃, min)
    10-30
    Complete cured time (25℃,h)
    8-12
    Cured
    Tensile strength (Mpa)
    ≥1.0
    Elongation (%)
    ≥100
    Shore hardness (A)
    60
    Volume resistivity (Ω·cm)
    ≥1 X 1014
    Dielectric strength (KV/mm)
    ≥20
    Thermal stability (℃)
    -50~+250
    Linear shrinkage (%)
    ≤0.5
    Thermal conductivity
    0.8
    Flame retardant rating
    UL94V-0
    Ps: Operation time is tested based on 100g adhesive.
    All data was measured by testing after 7 days curing under the condition of 25℃ and 55%RH.
    Packing & Delivery

    Packing.

    Component A: 25KG, plastic drum;

    Component B: 25KG, plastic drum;

    also can be customized.

    Storage and transportation.

    1. Avoid light, heat, and keep sealing(could be transported and stored as non-dangerous goods )

    2. Both shelf life are 1 year at 25℃.

    Operation process.

    1. Weighing component A and B according to the ratio of 1:1, stirring evenly after mixed, then inject it to components and module which needed to be potting protected. It would be better to injected along one side of the wall, which can reduce the generation of air bubbles.

    2. Placing the sealed component, and it would discharge bubbles by itself, if possible, vacuumizing and defoaming the mixed rubber before potting sealing. Directly cured at room temperature, usually the rubber will have elasticity within 1-6 hours.
